Brooks Automation Z-Axis Gimbal Linear-Drive Motor Assembly
About this part
Brooks Automation 015-1504-01 is a motor-driven linear-motion assembly for a gimbal Z axis. Exact-number package markings and photographs show a compact motor housing, long threaded output shaft, and attached wiring. Electrical ratings, shaft travel, thread pitch, dimensions, and parent-equipment compatibility are not established by publicly available manufacturer documentation and should be matched against the installed assembly or Brooks service records
Configurations vary. Verify the exact unit before choosing a replacement.
Key Facts
Specifications
| Manufacturer | Brooks Automation |
| Manufacturer part number | 015-1504-01 |
| Assembly type | Motor-driven linear-motion assembly for a gimbal Z axis |
| Output member | Long threaded shaft, as observed on the exact-number packaged unit |
| Connection | Attached multi-conductor wire lead, as observed on the exact-number packaged unit |
| Package description | ASSY, MOTOR, LINEAC, B/L |
| Application marking | MOTOR, Z, GIMBAL |
Observed Package Markings
The photographed package contains both manufacturer-part identification and transaction-specific markings. Only 015-1504-01 is treated as the Brooks part identifier.
| Marking | Value | Interpretation |
|---|---|---|
| Item | 015-1504-01 | Brooks part identifier |
| Description | ASSY, MOTOR, LINEAC, B/L | Exact package text; “LINEAC” is retained without attempting an undocumented expansion |
| Application label | MOTOR, Z, GIMBAL | Identifies the observed assembly as a Z-axis gimbal motor |
| Customer item | 233343037 | Customer-side cross-reference on the observed package; not promoted to an OEM alias |
| Sales order | 159527 | Transaction-specific marking |
| Farmon ID / seller serial | 177722 | Seller inventory identifier; not a Brooks model or part-number alias |
Part Photos
5 imagesHistorical archive images for identification, labels, connectors, and condition reference, not current inventory.
Historical Listings & Prices
Historical listing data, not a current offerThe typical recorded price range is $350.00 to $350.00. Based on 1 archived listing record; not a current offer, appraisal, or confirmed sale price.
View archived listing titles
- Brooks 015-1504-01 Assy, Motor, Lineac, B/L, Gimbal, 177722
