Flow Measurement
1110CL20CJDAB
Brooks Instrument Full-View Glass-Tube Variable-Area Flowmeter
About this part
1110CL20CJDAB is a configured Brooks Full-View Model 1110 industrial glass-tube variable-area flowmeter. Its ordering-code positions identify a size 10 meter with horizontal 3/4-inch female NPT process connections and an R-10M-127-3 metering tube with a 127 mm nominal scale. The archived unit is presented with a separate flow-switch assembly marked 621210. Several legacy configuration characters are absent from later Brooks ordering tables; the calibrated fluid, flow range, scale inscription, float design and switch electrical ratings must therefore be taken from the instrument labels or original Brooks build record
Configurations vary. Verify the exact unit before choosing a replacement.
Key Facts
Specifications
| Manufacturer | Brooks Instrument |
| Product line | Full-View 1100 Series |
| Base model | 1110 |
| Instrument type | Industrial glass-tube variable-area flowmeter (rotameter) |
| Meter size | Size 10 (ordering-code position L) |
| Process connections | 3/4-inch female NPT |
| Connection orientation | Horizontal inlet and horizontal outlet |
| Metering tube | R-10M-127-3, corresponding to size 10 tube-designator code 2 |
| Nominal scale length | 127 mm |
| Float material code | C, identified in the Brooks ordering table as 316 stainless steel; the preceding legacy float-designator code 0 is not defined in the later table |
| Materials code | D, identified as 316 stainless-steel end fittings with Teflon packing and Teflon O-ring |
| Metering-tube material | Borosilicate glass |
| Family flow accuracy | Standard ±2% of full scale; optional ±1% of full scale. The exact calibration option is not resolved by the surviving legacy code |
| Family repeatability | 0.5% of full scale |
| Family ambient-temperature range | 33 to 125°F (1 to 52°C) |
| Family process-fluid temperature range | 33 to 250°F (1 to 121°C) with metallic end fittings; installed accessory limits may be lower |
| Size 10 family rating | 100 psig maximum non-shock pressure at 70°F, 150°F and 250°F for the original 1110/1140 family with metal end fittings; the unit nameplate and accessory ratings govern |
Model-code interpretation
The identifier uses an earlier Full-View ordering-code revision. Positions that remain defined in later Brooks literature can be decoded, while obsolete or custom characters require the original build record.
| Code segment | Meaning | Interpretation |
|---|---|---|
| 1110 | Base model | Full-View glass-tube flowmeter with horizontal threaded process connections |
| L | Meter size | Size 10; Model 1110 uses 3/4-inch NPT connections at this size |
| 2 | Tube designator | R-10M-127-3 metering tube with 127 mm nominal scale |
| 0 | Float designator | Legacy value not defined in the later Brooks ordering table |
| C | Float material | 316 stainless steel |
| J | Scale inscription/calibration | Legacy or custom value not defined in the later ordering table; do not infer the calibrated fluid or range |
| D | Materials of construction | 316 stainless-steel fittings with Teflon packing and Teflon O-ring |
| A | Connection type | NPT |
| B | Accessory position | Legacy value not defined in the later ordering table; market evidence shows a flow-switch assembly, but the code-to-accessory relationship is not established by the available manufacturer literature |
Installation and glass-tube safety
- Mount the flowmeter within 6 degrees of true vertical, with the process inlet at the bottom and outlet at the top.
- For size 10, the protective sleeve must remain over the glass tube and the meter windows must remain securely fastened.
- Avoid pressure and flow surges, and do not service or repair the meter while it is pressurized.
- Brooks strongly recommends bypass piping so the meter can be isolated for cleaning and service.
- Introduce flow slowly and verify tube-to-scale zero alignment before operation.
Retrofit and replacement context
Brooks identifies the GT1600 Series as configurable to retrofit Full-View 1100 Series meters, including Model 1110. A replacement must be selected for the original size 10 geometry, horizontal 3/4-inch NPT connections, R-10M-127-3 tube/scale duty and any required alarm or flow-switch function. Retrofit capability is family-level guidance, not an automatically interchangeable exact replacement for 1110CL20CJDAB.
Documentation Downloads
Local PDF copiesPart Photos
5 imagesHistorical archive images for identification, labels, connectors, and condition reference, not current inventory.
Historical Listings & Prices
Historical listing data, not a current offerThe typical recorded price range is $1,495.00 to $1,495.00. Based on 1 archived listing record; not a current offer, appraisal, or confirmed sale price.
View archived listing titles
- Brooks Instrument 1110CL20CJDAB Rotameter & Flow Switch Assy 621210 + Warranty!
